Description
Hanjin Power 7000D multipurpose drill with very low hours and well-maintained condition. The drill has had several serious upgrades in the past few years including a new Versadrill rotation head and chuck in 2022.
Truck and drill details.
Truck
MAN 32-403 8X4
Date of manufacture 1999
Overhauled MAN diesel engine D2866 400 hp engine @ 493,000 Km.
Current kilometers 495000
Drill Rig Details
Manufacturer – Hanjin
Date of manufacture 2004
Model – Power 7000D
Fitted with a Hyundai D6CA -G diesel engine rated to 460 Hp
Engine hours 3095
30 ton pull back
11.7 ton pull down
Head travel 7.5m
Dump Mast 2.0m
Extended mast for 9m rod pull
Overhauled Hyundai D6CA -G rotation head reconditioned in 2022
Versadrill KmN1.4 rotation head and chuck in 2022
Components added
Versadrill KmN1.4 PQ chuck drive rotation head, 160cc motor, 2-speed hydraulic gearbox
X spec PQ foot clamp 40,000 Lbs (18,000 Kg)
MPP 4000ft level wind winch
Braden H20R winch 20,000 lb (9,070 kg)
Bean M1222 RO mud pump (70 gpm 1500psi) converted to AR valves
Bean L0918 HD high-pressure triplex pump
Components removed but still available
Auxiliary winch with 16mm rope for rod handling (requires overhaul)
2 x K3V180, 1 x K3V63 pumps (requires overhaul)
Hydraulic drive 200 l/min 70 bar mud pump
2,065
